＜Uncompressed SSD Recorder＞VMR-1500

High Reliable Uncompressed Recording with SSD .

High Quality Uncompressed Recorder.

3U compact size.

[discontinued]

・3D Recording (3G-SDI / Dual Link , HD SDI )

・Intuitive operation like VTR

・5.7 inch LCD with touch panel function

img02_item02

Digital Video
Video format	HD-SDI	1920×1080 4:2:2 10bit	23.98p, 23.98PsF, 24p, 24PsF, 50i, 59.94i
	3G-SDI/Dual Link	1920×1080 4:4:4 12bit	23.98p, 23.98PsF, 24p, 24PsF, 50i, 59.94i
		1920×1080 4:2:2 10bit	50p, 59.94p
Digital Video
Sampling rate			48KHz
Recording data format			24bit×8ch
Input and output specification
SDI	Iput		SMPTE424M(Level-B),SMPTE372M,SMPTE292MBNC×2ch(Dual link 2ch,single link 1ch)
	Output		SMPTE424M(Level-B),SMPTE372M,SMPTE292MBNC×2ch(Dual link 2ch,single link 1ch)
Phone Jack			φ3.5mm Level adjustment function
Time Code	Input		BNC×1
	Output		BNC×2
Remote Control			RS-422A,LAN,Parallel
Reference Iput			BNC75Ω Bi-Level Sync 0.3Vp-p,Tri-Level Sync 0.6Vp-p
General Specification
Power Supply			AC100V～240V or DC12V 4Pin
Power Consumption			Under 80W
Operating tempature			0℃～40℃
Operating humidity			10％RH～80％RH(No Dew condensation)/td>
Demension			215（W）×130（H）×425（D）mm (Without protrusions)
Weight			5.5Kg(Include SSD Pack)
Dedicated SSD Pack			1 unit
